O CTOBER 2006 VXA-320 T APE D RIVE 5
C
OMPONENTS
T
APE
D
RIVE
L
ABELS
The VXA-320 tape drive includes two labels:
The top-panel label ( Figure 1-6 ) shows the tape drive’s part number, serial
number, revision, connector type, and agency information.
The back-panel label ( Figure 1-7 ) identifies the tape drive connectors and
jumpers.
Depending on the model tape drive you have, the labels on your tape drive
may differ.
Caution
Do not remove or modify these labels. If you do so, you will void the product
warranty.
Figure 1-6 Top-panel label (SCSI tape drive)
Figure 1-7 Back-panel label (SCSI tape drive)
