2
P RODUCT M ANUAL 433689-01
C
HAPTER
1 F
EATURES
Both the internal and external models of the VXA-320 tape drive are available
with a wide, High-density (HD), 68-pin low-voltage differential (LVD) SCSI
interface.
C
OMPONENTS
This section describes the major components of both the internal and external
models of the tape drive.
F
RONT
P
ANEL
C
OMPONENTS
Figure 1-2 and Figure 1-3 show the controls and indicators on the front panel
of the tape drive. For more information about using these controls and
indicators, see Chapter 3 .
Door Used for inserting the cartridge into the tape drive.
Eject Button Used to unload the tape and eject the cartridge.
Figure 1-2 Internal tape drive: front-panel components
Figure 1-3 External tape drive: front-panel components
3
Door
1 2 3 4
Status LEDs Eject button
Ventilation
holes
3
Status LEDs
1 2 3 4
Eject button
Door
Power LED
Ventilation
holes
