42 PTAC-SVX01C-EN
Troubleshooting
Table 31. Compressor output does not energize
Probable cause Explanation
Random restart timer All controller outputs remain off until the timer expires.
Selected mode OFF When off is selected at the display to the controller, the unit controls all outputs off.
Selected mode FAN ONLY When fan only is selected at the display to the controller, the unit only allows the indoor fan to energiz.
Diagnostic present A specific list of diagnostics affects compressor operation. For more information, see the Diagnostics section in the
manual.
No power to the
controller
If the controller does not have power, the compressor does not operate. For the controller to operate normally, it
must have an input voltage of 115 or 230/208, 265 VAC.
Manual output test The controller includes a manual output test sequence you can use to verify output operation and associated
output wiring. However, based on the current step in the test sequence, the compressor may not be on. Refer to
the Manual Output Test section.
Unit wiring The wiring between the controller output and the compressor must be present and correct for normal operation.
Indoor Coil Freeze
protection
The compressor has been turned off because the indoor coil temperature has fallen below 35°F and has not risen
above 50°F
Table 32. Indoor/remote fan outputs do not energize
Probable cause Explanation
Random restart timer All controller outputs remain off until the timer expires.
Normal operation Depending on the configuration selected the fan(s) may be only cycle with the compressor output
Selected mode OFF When off is selected at the display to the controller, the unit controls all outputs off.
Diagnostic present A specific list of diagnostics affects fan operation. For more information, see the Diagnostics section in the manual.
No power to the
controller
If the controller does not have power, the compressor does not operate. For the controller to operate normally, it
must have an input voltage of 230/208, 265 VAC.
Manual output test The controller includes a manual output test sequence you can use to verify output operation and associated output
wiring. However, based on the current step in the test sequence, the fan(s) may not be on. Refer to the Manual
Output Test section.
Unit wiring The wiring between the controller outputs and the fan relays and contacts must be present and correct for normal
fan operation.
Table 33. Outdoor fan output does not energize
Probable cause Explanation
Random restart timer All controller outputs remain off until the timer expires.
Selected mode OFF When off is selected at the display to the controller, the unit controls all outputs off.
Selected mode FAN ONLY When fan only is selected at the display to the controller, the unit only allows the indoor fan to energize.
Diagnostic present A specific list of diagnostics affects compressor and therefore the outdoor fan operation. For more information, see
the Diagnostics section in the manual.
No power to controller If the controller does not have power, the compressor does not operate. For the controller to operate normally, it
must have an input voltage of 115 or 230/208, 265 VAC.
Manual output test The controller includes a manual output test sequence you can use to verify output operation and associated output
wiring. However, based on the current step in the test sequence, the outdoor fan may not be on. Refer to the
Manual Output Test section.
Unit wiring The wiring between the controller output and the outdoor fan must be present and correct for normal operation.
Coil Burst Protection The outdoor fan has been turned off because the indoor coil temperature has risen above 140°F and has not fallen
below 125°F
Normal operation The outdoor fan cycles with the compressor output
Defrost Cycle During the active defrost cycle the outdoor fan is controlled off. See the section on defrost control.
Unit wiring The wiring between the controller outputs and the fan relays and contacts must be present and correct for normal
fan operation.
