28 PTAC-SVX01C-EN
Operation
Table 25. Unit accessory model numbers
Description Part Number
Architectural Grilles
ARCHITECTURAL ALUMINUM GRILLE
BAYAAGL001
ARCHITECTURAL ALUMINUM GRILLE -DARK
BRONZE
BAYAAGL002
ARCHITECTURAL ALUMINUM GRILLE - SOFT
DOVE
BAYAAGL003
ARCHITECTURAL ALUMINUM GRILLE - SPECIAL
COLOR
BAYAAGL004
Circuit breakers
CIRCUIT BREAKER - 208/230 15AMP
BAYCBKR001
CIRCUIT BREAKER 208/230 20AMP BAYCBKR002
CIRCUIT BREAKER - 208/230 30AMP BAYCBKR003
Condensate pump
CONDENSATE PUMP 208/230
BAYCPMP001
CONDENSATE PUMP 265 BAYCPMP002
Drain Kit
DRAIN KIT
BAYDRAN001
Filters
SPARE FILTERS 10 PACK
BAYFLTR009
Hard Wire Kit
HARD WIRE KIT
BAYHWRK001
Leveling Legs
LEVELING LEG
BAYLVLG001
Power Switch (1)
POWER SWITCH -115V, 208/230V 265V 30 AMP BAYPSW002
Stamped grille
STAMPED ALUMINUM GRILLE - SINGLE PACK
BAYSAG001
STAMPED ALUMINUM GRILLE - TEN PACK BAYSAG002
Wall Sleeve
13 INCH WALL SLEEVE
BAYWSLV001
18 INCH WALL SLEEVE BAYWSLV002
24 INCH WALL SLEEVE BAYWSLV003
Power Cord
UNIVERSAL POWER CORD 115 VOLT
- 15 Amp BAYPCRD007
UNIVERSAL POWER CORD 230 VOLT - 15 AMP BAYPCRD001
UNIVERSAL POWER CORD 230 VOLT - 20 AMP BAYPCRD002
UNIVERSAL POWER CORD 230 VOLT - 30 AMP BAYPCRD003
UNIVERSAL POWER CORD 265 VOLT - 15 AMP BAYPCRD004
UNIVERSAL POWER CORD 265 VOLT - 20 AMP BAYPCRD005
UNIVERSAL POWER CORD 265 VOLT - 30 AMP BAYPCRD006
Display Module
DISPLAY MODULE (AMERICAN STANDARD LOGO
STANDARD)
BAYAMDM001
DISPLAY MODULE (AMERICAN STANDARD LOGO
& DEHUMIDIFICATION)
BAYAMDM002
DISPLAY MODULE (TRANE LOGO STANDARD) BAYTRDM001
DISPLAY MODULE (TRANE LOGO &
DEHUMIDIFICATION)
BAYTRDM002
Escutcheon Cover (2)
ESCUTCHEON COVER FOR FRONT PANEL
(AMSTD LOGO)
BAYACVR001
ESCUTCHEON COVER FOR FRONT PANEL
(TRANE LOGO)
BAYTCVR001
Plastic Front Cover (3)
PLASTIC FRONT COVER FOR PTAC BAYPCVR001
Connector for Hardwire (4)
CONNECTOR FOR HARDWIRE KIT 208/230V -
15 AMP
BAYCNHK011
CONNECTOR FOR HARDWIRE KIT 208/230V -
20 AMP
BAYCNHK012
CONNECTOR FOR HARDWIRE KIT 208/230V -
30 AMP
BAYCNHK013
CONNECTOR FOR HARDWIRE KIT 265V - 15
AMP
BAYCNHK021
CONNECTOR FOR HARDWIRE KIT 265V - 20
AMP
BAYCNHK021
CONNECTOR FOR HARDWIRE KIT 265V - 30
AMP
BAYCNHK023
CONNECTOR FOR HARDWIRE KIT 115V - 15
AMP
BAYCNHK031
Subbase (5) (6)
UNIVERSAL SUBBASE BAYSUB001
SOCKET FOR SUBBASE 208/230 20 AMP BAYSCKT001
SOCKET FOR SUBBASE 208/230 30 AMP BAYSCKT002
SOCKET FOR SUBBASE 265 20 AMP BAYSCKT003
SOCKET FOR SUBBASE 265 30AMP BAYSCKT004
(1) The power switch can be installed on the hard wire junction box and
provides a way to shut on and off the PTAC unit. It is an optional ac-
cessory when using the power cord to power the PTAC unit. Check local
codes for approval
(2) This escutcheon cover should be ordered whenever the display module
is wall mounted or a thermostat or third party provider unit controls are
ordered. This escutcheon includes a control cover plate that covers the
normal unit mounted nomenclature. It comes 5 pieces per pack.
(3) All hydronic PTAC chassis come standard without a plastic front cover.
If a unit is required to work without heat and without a hydronic kit the
plastic front cover should be ordered.
(4) Not required when using a Hard Wire Kit.
(5) Provides a space to tie into a building’s wiring with a receptacle to plug
the unit into. It gives additional leveling and support capabilities and
provides a place for fuses, a circuit breaker or a mechanical disconnect
to be mounted. (30A is for units with 5kW electric heat, 20A for 3kW or
less electric heat.)
(6) All subbases require a socket. For 15 and 20 amp, the 20amp socket
can be used on either the 208/230V or the 265V.
