Installation
Table 14. PTEE manual test sequence
Step
Indoor
Fan High
Indoor
Fan Low
Remote
Fan
Outdoor
Fan
Condensate
Pump Comp
Reversing
Valve Aux. Heat
Ventilation
Door/Fan
Time in
Step
1 All off Off Off Off Off N/A (Off) Off N/A (Off) Off Off 10 sec
2 Fan high On Off Off Off N/A (Off) Off N/A (Off) Off Off 20 sec
3 Fan Low Off On Off Off N/A (Off) Off N/A (Off) Off Off 20 sec
4 Remote
Fan
Off On On Off N/A (Off) Off N/A (Off) Off Off 20 sec
5 Outdoor
Fan
Off On Off On N/A (Off) Off N/A (Off) Off Off 20 sec
6 Compres
sor
Off On Off On N/A (Off) On N/A (Off) Off Off 60 sec
7 Aux Heat Off On Off OnOff N/A (Off) Off N/A (Off) On Off 60 sec
8 Vent
Door
Off On Off OnOff N/A (Off) Off N/A (Off) Off On 20 sec
Exit
Table 15. PTHE manual test sequence
Step
Indoor
Fan High
Indoor
Fan Low
Remote
Fan
Outdoor
Fan
Condensate
Pump Comp
Reversing
Valve
Aux
Heat
Ventilation
Door/Fan
Time in
Step
1 All off Off Off Off Off Off Off Off Off Off 10 sec
2 Fan High On Off Off Off Off Off Off Off Off 20 sec
3 Fan Low Off On Off Off Off Off Off Off Off 20 sec
4 Remote Fan Off On On Off Off Off Off Off Off 20 sec
5 Outdoor Fan Off On Off On Off Off Off Off Off 20 sec
6 Condensate
Pump
Off On Off On On1 Off Off Off Off 20 sec
7 Compressor
on Cooling
Off On Off On Off On OffOn Off Off 60 sec
8 Compressor
Off
Off Off On Off On Off Off OffOn Off 60 sec
9 Compressor
on Heating
Off On Off On Off On OnOff Off Off 60 sec
10 Aux Heat Off On Off OnOff Off Off OnOff On Off 60 sec
11 Vent Door Off On Off OnOff Off Off Off Off On 20 sec
Exit
