Table 18. Heat pump performance
PTHE 07
PTHE 09
PTHE 12
PTHE 15
Voltage (V)
208
230
265
208
230
265
208
230
265
208
230
265
Cooling data
Cooling
capacity(Btu/H)
7,200 7,400
7,200 8,900 9,100
8,700
11,700
12,000 11,700 13,300 13,600 13,600
Cooling amps
(A)
2.9
2.7
2.3
3.9
3.7
3.1
5.1
4.8
4.2
6.8
6.3
5.5
EER(Btu/H watt) 12.0
12.0
12.0
11.4
11.4
10.8
11.2
11.2
11.0
9.9
9.9
9.9
Moisture
removal (Pts/h)
2.1
2.1
2.1
2.5
2.6
2.6
3.0
3.1
3.1
4.1
4.1
4.1
Heat pump
heating data
Heating capacity
(Btu/H)
5,900 6,100
6,100 7,600 7,800
7,300
9,900
10,100 10,100 12,200 12,500 12,500
Heating amps
(A)
2.6
2.5
2.1
3.4
3.2
2.6
4.3
4.0
3.5
5.8
5.4
4.7
Heating power
(W)
540
560
560
695
715
715
935
955
925
1230
1260
1260
COP (W/W)
3.2
3.2
3.2
3.2
3.2
3.0
3.1
3.1
3.2
2.9
2.9
2.9
Airflow
Indoor cfm (wet)
@0.3 esp (hi)
225
256
256
225
256
256
295
325
325
320
350
350
Indoor cfm (wet)
@0.3 esp (lo)
191
225
225
191
225
225
266
294
294
290
320
320
Indoor cfm (dry)
@0.3 esp (hi)
260
290
290
260
290
290
320
350
350
365
400
400
Indoor cfm (dry)
@0.3 esp (lo)
235
266
266
235
266
266
293
323
323
330
360
360
Electric heat
data
Heater size
(kW)
208V
1.6
2.4
*
1.6
2.4
4.0
1.6
2.4
4.0
1.6
2.4
4.0
230V
2.0
3.0
*
2.0
3.0
5.0
2.0
3.0
5.0
2.0
3.0
5.0
265V
2.0
3.0
*
2.0
3.0
5.0
2.0
3.0
5.0
2.0
3.0
5.0
Btu/H
208V
5,500 8,200
*
5,500 8,200
13,700
5,500
8,200
13,700 5,500
8,200
13,700
230V
6,800 10,200 *
6,800 10,200 17,100
6,800
10,200 17,100 6,800
10,200 17,100
265V
6,800 10,200 *
6,800 10,200 17,100
6,800
10,200 17,100 6,800
10,200 17,100
Heating watt
208V
1,600 2,400
*
1,600 2,400
4,000
1,600
2,400
4,000
1,600
2,400
4,000
230V
2,000 3,000
*
2,000 3,000
5,000
2,000
3,000
5,000
2,000
3,000
5,000
265V
2,000 3,000
*
2,000 3,000
5,000
2,000
3,000
5,000
2,000
3,000
5,000
Heating amps
208V
7.9
11.8
*
7.9
11.8
19.7
7.9
11.8
19.7
7.9
11.8
19.7
230V
8.9
13.4
*
8.9
13.4
22.2
8.9
13.4
22.2
8.9
13.4
22.2
265V
7.7
11.6
*
7.7
11.6
19.3
7.7
11.6
19.3
7.7
11.6
19.3
