Toshiba Strata DK8 - Manual (Page 298)

REMOTE ADMINISTRATION AND MAINTENANCE PROCEDURES
SECTION 100-816-600
MARCH 1993
-48-
TABLE RM-AU
PROGRAM 46-10 ~ 40
TOLL RESTRICTION CLASS PARAMETERS
ACTION STEP DISPLAY/PRINTOUT
1 >MODE PROG
P
Enter Program Mode
At the >MODE prompt, enter
P R O G CR .
2 P 46
P46
Enter Program Number 46
3 P46 10 Refer to the System Record Sheet and enter the Toll Restriction
class number (1 ~ 4). Then enter the number
0 .
Example: Class 1, enter 1 0 .
6 To Exit Program/Store Data
Press CR .
4 Refer to the System Record Sheet and enter the required
button/LED number.
Example: Button number 11, enter
1 1 . The system will display
the status of the button/LED.
P46 10 11 TABLE 1N
A)
B) To store data, press CR .
To exit this program, press # # CR .
5 Refer to the System Record Sheet and change if required (Y or N).
To access next button number, press
SPACE .
P46 10 11 TABLE1 N Y
12 TABLE2 N
P46 10 11 TABLE1 N Y
P46 ##
P
12 TABLE2 N
