EMAC Module Registers
www.ti.com
5.9
Transmit Interrupt Mask Set Register (TXINTMASKSET)
The transmit interrupt mask set register (TXINTMASKSET) is shown in
and described in
Figure 47. Transmit Interrupt Mask Set Register (TXINTMASKSET)
31
16
Reserved
R-0
15
8
Reserved
R-0
7
6
5
4
3
2
1
0
TX7MASK
TX6MASK
TX5MASK
TX4MASK
TX3MASK
TX2MASK
TX1MASK
TX0MASK
R/W1S-0
R/W1S-0
R/W1S-0
R/W1S-0
R/W1S-0
R/W1S-0
R/W1S-0
R/W1S-0
LEGEND: R/W = Read/Write; R = Read only; W1S = Write 1 to set (writing a 0 has no effect); -n = value after reset
Table 46. Transmit Interrupt Mask Set Register (TXINTMASKSET) Field Descriptions
Bit
Field
Value
Description
31-8
Reserved
0
Reserved
7
TX7MASK
0-1
Transmit channel 7 interrupt mask set bit. Write 1 to enable interrupt, a write of 0 has no effect.
6
TX6MASK
0-1
Transmit channel 6 interrupt mask set bit. Write 1 to enable interrupt, a write of 0 has no effect.
5
TX5MASK
0-1
Transmit channel 5 interrupt mask set bit. Write 1 to enable interrupt, a write of 0 has no effect.
4
TX4MASK
0-1
Transmit channel 4 interrupt mask set bit. Write 1 to enable interrupt, a write of 0 has no effect.
3
TX3MASK
0-1
Transmit channel 3 interrupt mask set bit. Write 1 to enable interrupt, a write of 0 has no effect.
2
TX2MASK
0-1
Transmit channel 2 interrupt mask set bit. Write 1 to enable interrupt, a write of 0 has no effect.
1
TX1MASK
0-1
Transmit channel 1 interrupt mask set bit. Write 1 to enable interrupt, a write of 0 has no effect.
0
TX0MASK
0-1
Transmit channel 0 interrupt mask set bit. Write 1 to enable interrupt, a write of 0 has no effect.
