Operating Instructions
1705A Spectrum Monitor 2- 13
1400 MHZ
POINT ON THE TRACE THAT
CORRESPONDS TO 1400 MHZ.
CENTER FREQUENCY
TUNED AT THIS POINT.
Figure 2-8: 1705A CRTwith the SCALE turned down to show the relationship
between the alphanumeric readout and the front-panel CENTER FREQUENCY
tuning
1400 MHZ
POINT ON THE
TRACE THAT
CORRESPONDS TO
1400 MHZ.
CENTER FREQUENCY
TUNED AT THIS POINT.
Figure 2-9: The setting of the HORIZONTAL POSITION control can displace the
location of the displayed center frequency
