Tektronix 1705A - Manual (Page 182)

Replaceable Electrical Parts
1705A Spectrum Monitor 8- 23
Component
Number Mfr. Part
Number Mfr.
Code
Name & Description Effective Discontinued
Tektronix
Part Number
A3R202 322--3134--00 RES,FXD,FILM:243 OHM,1%,0.2W,TC=T0 80009 322--3134--00
A3R203 322--3134--00 RES,FXD,FILM:243 OHM,1%,0.2W,TC=T0 80009 322--3134--00
A3R204 322--3289--00 RES,FXD:MET FILM;10K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
80009 322--3289--00
A3R205 322--3281--00 RES,FXD:MET FILM;8.25K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
80009 322--3281--00
A3R206 322--3134--00 RES,FXD,FILM:243 OHM,1%,0.2W,TC=T0 80009 322--3134--00
A3R207 322--3134--00 RES,FXD,FILM:243 OHM,1%,0.2W,TC=T0 80009 322--3134--00
A3R208 322--3305--00 RES,FXD,FILM:14.7K OHM,1%,0.2W,TC=T0 80009 322--3305--00
A3R209 322--3289--00 RES,FXD:MET FILM;10K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
80009 322--3289--00
A3R210 322--3318--00 RES,FXD:MET FILM;20K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 20K0
A3R211 322--3097--00 RES,FXD:MET FILM;100 OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 100E
A3R212 322--3222--00 RES,FXD:MET FILM;2K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 2K00
A3R213 322--3097--00 RES,FXD:MET FILM;100 OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 100E
A3R214 322--3258--00 RES,FXD:MET FILM;4.75K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
80009 322--3258--00
A3R215 322--3318--00 RES,FXD:MET FILM;20K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 20K0
A3R216 322--3281--00 RES,FXD:MET FILM;8.25K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
80009 322--3281--00
A3R217 322--3235--00 RES,FXD:MET FILM;2.74K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 2K74
A3R218 322--3289--00 RES,FXD:MET FILM;10K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
80009 322--3289--00
A3R219 322--3306--00 RES,FXD:MET FILM;15K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 15K0
A3R220 322--3165--00 RES,FXD,FILM:511 OHM,1%,0.2W,TC=T0 57668 CRB20 FXE 511E
A3R221 322--3165--00 RES,FXD,FILM:511 OHM,1%,0.2W,TC=T0 57668 CRB20 FXE 511E
A3R222 322--3306--00 RES,FXD:MET FILM;15K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 15K0
A3R223 322--3097--00 RES,FXD:MET FILM;100 OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 100E
A3R224 322--3235--00 RES,FXD:MET FILM;2.74K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 2K74
A3R225 322--3201--00 RES,FXD:MET FILM;1.21K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
80009 322--3201--00
A3R226 322--3342--00 RES,FXD,FILM:35.7K OHM,1%,0.2W,TC=T0 57668 CRB20 FXE 35K7
A3R227 322--3361--00 RES,FXD:MET FILM;56.2K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
91637 CCF50--2F56201F
A3R228 322--3277--00 RES,FXD,FILM:7.5K OHM,1%,0.2W,TC=T0 57668 CRB20 FXE 7K50
A3R229 322--3269--02 RES,FXD,FILM:6.19K OHM,0.2W,5% 80009 322--3269--02
A3R230 322--3269--02 RES,FXD,FILM:6.19K OHM,0.2W,5% 80009 322--3269--02
A3R231 322--3289--00 RES,FXD:MET FILM;10K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
80009 322--3289--00
A3R232 311--2231--00 RES,VAR,TRMR:CERMET;1K OHM,20%,0.5W,0.197 SQ,TOP
ADJUST;T&R
TK1450 GF06UT 1K
A3R233 322--3222--00 RES,FXD:MET FILM;2K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 2K00
A3R234 322--3326--00 RES,FXD,FILM:24.3K OHM,1%,0.2W,TC--T0 91637 CCF50--2F24301F
A3R235 322--3239--00 RES,FXD,FILM:3.01K OHM,1%,0.2W,TC=T0 57668 CRB20 FXE 3K01
A3R236 322--3258--00 RES,FXD:MET FILM;4.75K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
80009 322--3258--00
A3R237 322--3222--00 RES,FXD:MET FILM;2K OHM,1%,0.2W,TC=100 PPM;AX-
IAL,T&R,SM BODY
57668 CRB20 FXE 2K00
A3R238 322--3254--00 RES,FXD,FILM:4.32K OHM,1%,0.2W,TC=T0 80009 322--3254--00
