Tascam CD-RW700 - Manual (Page 28)

6 - Reference and specifications
6.1 Troubleshooting
6.2 Specifications
Symptom Possible cause and remedy
No sound on playback
(the disc is playing and
the time display is
incrementing) The connections from the CD-RW700 to
the amplifier system have not been made
properly, or the input source selector is
not at the correct position.
No meter indication
when a source is input Analog and/or digital volume (4.1.1, “Sig-
nal volume”) is set too low. The signal is
being input through an unselected input
source (4.1, “Input selection”)
D-IN UNLOCK! A digital input source has been selected,
but the source is not connected or is not
switched on.
Cannot record on a
disc (pressing
RECORD shows
MONITOR )
A finalized disc has been inserted. Use
an unfinalized recordable disc.
PGM Full ! An attempt has been made to create
more than 25 program steps.
Disc Full! or
Cannot Rec!
There is no space on the disc, or no
tracks are available, or a general record-
ing error has occurred
SCMS !! You are trying to record digitally from a
“second-generation” digital copy. Try ana-
log recording (4.3.3, “SCMS and the CD-
RW700”.
Not FS 44.1k! You are trying to do digital direct record-
ing from a source which has not been
recorded at 44.1 kHz (4.3.4, “Digital
direct”)
No Inc Mode Auto track is not on when an attempt is
being made to rehearse track split times.
Timer Error! An attempt has been made to set timer
recording (2.5.3, “Using the timer”) with a
non-recordable disc, or no disc.
Disc Error The disc is bad. If it is a CD-RW disc, you
may refresh it (5.2.3, “Refreshing a
disc”), otherwise replace the disc.
Erase Error! An error has occurred while trying to
erase the disc
The display suddenly
shows
PMA
Writing
Either the disc is full (this message will
be prefaced by
Disc Full!!
(4.2.5, “Full disc”) or an attempt has been
mode to write more than 99 tracks.
Rec Error General recording error. This may be
caused by vibration or a shock during
recording, for example, or may be the
result of a bad disc. Try recording again
with the same disc. If the message
appears again, try a different disc.
No OPC Area! Appears only with CD-R discs. The OPC
area is full, and no further recording is
possible on this disc. Finalize the disc.
OPC Area CLR Seen when a CD-RW disc OPC area is
full, and the CD-RW700 automatically
cleans up the OPC area for further
recording.
Need Repair! ,
System Err! ,
Tray Error! ,
Drive Error!
These messages indicate an internal
error in the unit. Consult your dealer or
distributor regarding repair facilities.
Recording media type CD-R, CD-RW
Recording resolution 16-bit linear
Recording sampling fre-
quency 44.1 kHz
Frequency convertor input 32 kHz — 48 kHz
Frequency response 20 Hz — 20 kHz (playback ±0.5 dB,
recording ±1 dB)
S/N ratio 98 dB (playback)
92 dB (recording)
Dynamic range 94 dB (playback)
92 dB (recording)
Total harmonic distortion 0.004% (playback)
0.005% (recording)
Channel separation 90 dB (playback : 1 kHz)
80 dB (recording : 1 kHz)
Wow & flutter Unmeasurable (< 0.001%)
Analog inputs Unbalanced RCA
Nominal input level –10 dBV (FS –16 dB)
Maximum input level + 6dBV
Input impedance 33 k
Ω
(unbalanced)
Analog outputs Unbalanced RCA
Nominal output level –10 dBV (FS –16 dB)
Maximum output level+6 dBV
Output impedance 800
Ω
(unbalanced)
Headphone output 6 mm (1/4”) stereo
Output level 35 mW + 35 mW (into 32
Ω
)
Digital inputs
COAXIAL RCA pin, IEC60958 TYPE II
OPTICAL TOSLINK , IEC60958 TYPE II
Digital outputs
COAXIAL RCA pin, IEC60958 TYPE II
OPTICAL TOSLINK , IEC60958 TYPE II
Voltage requirements USA/Canada 120 VAC, 60 Hz
U.K./Europe 230 VAC, 50 Hz
Australia 240 VAC, 50 Hz
General export 120/230 VAC, 60 Hz
Power consumption 27 W
Dimensions w x h x d 483 x 98 x 312 (mm)
19 x 3.9 x 12.3 (in)
Weight 6.3 kg (13.9 lbs)
Operating temperature 5˚C to 35˚C (41˚F to 95˚F)
Supplied accessories RC-RW700 remote control unit
2 x type 3 (AA) batteries
Symptom Possible cause and remedy
