59
Other Cables
Table 7: M1012 Adapter Board to Motherboard
M1012 Connect to Motherboard
J1 Front Panel connector Æ J24 (TYFP1)
J3 (LAN / ID LED) Æ J5 (TYFP2)
Table 8: M1003 Front Panel Control Board Related Cable
M1003 J1 USB connector Æ Motherboard J22 USB2
M1003 J2 connector Æ M1012 J2 connector
Table 9: CD-ROM Related Cable
Motherboard PRE-IDE con-
nector
Æ CD-ROM Backplane
M1012 J19 power connector Æ CD-ROM Backplane
Table 10: FDD Related Cable (Option)
M1012 FDD1 connector Æ Motherboard JB1 FDD
M1012 FDD2 connector Æ Slim FDD drive
