Chapter 3: Replacing Pre-Installed Components

47

J10 Fan Connector

J11 Fan Connector

J9 Fan Connector

1

FAN3_12VPWM

2

FAN3_TACH

3

GND

4

GND

5

FAN4_TACH

6

FAN4_12VPWM

1

FAN5_12VPWM

2

FAN5_TACH

3

GND

4

GND

5

FAN6_TACH

6

FAN6_12VPWM

1

FAN7_12VPWM

2

FAN7_TACH

3

GND

4

GND

5

FAN8_TACH

6

FAN8_12VPWM
