Chapter 2: Setting Up 29
5. Connect the FFC cable to the connector on M1012
adapter board.
6. Locate the FDD cable from FDD kit. Connect the wrinkle
side to the connector on M1012 adapter board. Refer to
the picture below for the correct direction.
7. Connect the other side to the connector on motherboard.
For M1012
For Mainboard
