Chapter 1: Overview

7

1.5.4 Internal View

1

2

6

11

9

10

5

7

8

3

12

4

1. PCI-X Slot

2. Memory Slots

3. Power Connector

4. EPS Power Supply

5. System Fans

6. M1012 Adapter Board

7. SATA Backplane

8. LED Control Board Cable

9. SATA Cables (4)

10. USB Cable

11. CD-ROM Cable

12. Four SATA HDD Bays

13. Slim CD-ROM

13
