56
S3970 Advanced/Hardware Health Configuration
Table of Differences
BIOS Setup Utility
Advanced
Hardware Health Configuration Enables Hardware
Health Monitoring
Device
ÅÆ Select Screen
ÇÈ
Select Item
+ - Change Option
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
H/W Health Function
FAN Select
Auto FAN1, 2 Power Control
Auto FAN 3, 4 Power Control
FAN Fail LED Indicator
Hardware Health Event Monitoring
[Enabled]
[4Pin FAN]
[Disabled]
[Disabled]
[Disabled]
XMainboard Voltages Report
CPU1 Temperature
Mainboard Ambient Temp.
FAN1 Speed
FAN2 Speed
FAN3 Speed
FAN4 Speed
:xx ºC/ xxx ºF
:xx ºC/ xxx ºF
:xxxx RPM
:xxxx RPM
:xxxx RPM
:xxxx RPM
S3970 B3970-U
FAN Select 4Pin FAN 3Pin FAN
Fan Power Control Disabled Enabled
PWM Minimal Duty
Cycle [10% Duty Cycle] --
FAN Fail LED
Indicator Disabled Enabled
Hardware Monitor
Fan FAN1 Speed
FAN2 Speed
FAN3 Speed
FAN4 Speed System FAN1 Speed
System FAN2 Speed
System FAN3 Speed
System FAN4 Speed
