F3S-B
7
J
SERIES CONNECTION TYPES
The following charts show the response time of combinations of a
Master Unit and a Slave Unit, and then they show combinations
of a Slave Unit connected in series. For example, the response
time of the combination of F3S-BM122P30 and F3S-BS302 is
30 ms.
Master unit
Response Time per Slave Unit F3S-
BS122
BS182
BS242
BS302
F3S-BM122Pjj
20 ms
23 ms
27 ms
30 ms
F3S-BM182Pjj
23 ms
27 ms
30 ms
34 ms
F3S-BM242Pjj
27 ms
30 ms
34 ms
37 ms
F3S-BM302Pjj
30 ms
34 ms
37 ms
41 ms
F3S-BM362Pjj
34 ms
37 ms
41 ms
45 ms
F3S-BM422Pjj
37 ms
41 ms
45 ms
49 ms
F3S-BM482Pjj
41 ms
45 ms
49 ms
54 ms
F3S-BM542Pjj
45 ms
49 ms
54 ms
57 ms
F3S-BM602Pjj
49 ms
54 ms
57 ms
61 ms
F3S-BM662Pjj
54 ms
57 ms
61 ms
65 ms
Master Unit
Response Time per Slave Unit F3S-
U
BS047
BS067
BS087
BS107
F3S-BM047Pjj
20
20
20
20
F3S-BM067Pjj
20
20
20
20
F3S-BM087Pjj
20
20
20
20
F3S-BM107Pjj
20
20
20
20
F3S-BM127Pjj
20
20
20
21
F3S-BM147Pjj
20
20
21
23
F3S-BM167Pjj
20
21
23
24
F3S-BM187Pjj
21
23
24
25
F3S-BM207Pjj
23
24
25
26
F3S-BM227Pjj
24
25
26
27
Master Unit
Response Time per Slave Unit F3S-
U
BS065
BS095
BS125
BS155
F3S-BM065Pjj
20
20
20
21
F3S-BM095Pjj
20
20
21
22
F3S-BM125Pjj
20
21
22
24
F3S-BM155Pjj
21
22
24
26
F3S-BM185Pjj
22
24
26
28
F3S-BM215Pjj
24
26
28
30
F3S-BM245Pjj
26
28
30
32
F3S-BM275Pjj
28
30
32
34
F3S-BM305Pjj
30
32
34
35
F3S-BM335Pjj
32
34
35
37
