Specifications Table -- continued from previous page
Type F3S-BjjjP (See Note 1)
Stand-Alone
F3S-BjjjPjj (See Note 1)
Master Unit for series connection
F3S-Bjjj (See Note 1)
Master Unit for series connection
Protective height 300 / 450 / 600 / 750 / 900 / 1,050 / 1,200 / 1,350 / 1,500 / 1,650 mm 300 / 450 / 600 / 750 mm
Detection distance 0.3 to 5.0 m
Response time ON to OFF: See table Response Time
OFF to ON (See note 2): Default 100 ms (selectable with F39--U1E, 80 to 400 ms)
Startup waiting time 2 s max.
Supply voltage: Vs 24 VDC ±20% (including 5 Vp-p ripple)
Current consumption 400 mA max. (under no-load conditions)
Light source Infrared LED (880 nm wavelength). Lifetime: 50,000 hrs. at 25 °C.
Effective aperture angle Within ±5° for the emitter and receiver at a detection distance of at least 3 m according to IEC 61496--2
Operating mode
Light ON
Control output Two PNP transistor outputs, load current 200 mA max., residual voltage 2 V max. (except for voltage drop
due to cable extension)
Instability output PNP transistor output (not safety--related control output),
activated during an insufficient light detection, failure detection and connection with F39--E1,
load current 100 mA max., residual voltage 2 V max. (except for voltage drop due to cable extension)
Protection circuit Output short--circuit protection, power supply reverse connection protection
Start/restart interlock Mode selection before power ON by connecting Interlock selection input line to: Start/restart interlock
function
Mode selection before power ON by connecting Interlock selection input line to:
Active: No connection or 0 to 2.5 VDC, 3 mA max. function Active: No connection or 0 to 2.5 VDC, 3 mA max.
Inactive: Instability output line Inactive: Instability output line
Reset of start/restart interlock by connecting Interlock selection input line to: Reset of start/restart interlock by connecting Interlock selection input line to:
Interlock reset: 17 VDC to Vs, 20 mA max. Duration time 15 to 2,500 ms
External test function Mode selection by connecting External test input line to: External test function Mode selection by connecting External test input line to:
Active: 17 VDC to Vs, 10 mA max. Duration time at least 15 ms
I i N i VDC A
Active: 17 VDC to Vs, 10 mA max. Duration time at least 15 ms
Inactive: No connection or 0 to 2.5 VDC, 2 mA max.
Relay monitoring Default inactive, selectable with F39--U1E Relay monitoring
function (optional)
Default inactive, selectable with F39--U1E
Relay monitoring input line with NC contact connected function (optional) Relay monitoring input line with NC contact connected
Available level: 17 VDC to Vs, 10 mA max. Available level: 17 VDC to Vs, 10 mA max.
Allowed relay delay time: Selectable between 20 and 300 ms (See Note 2) Allowed relay delay time: Selectable between 20 and 300 ms (See Note 2)
Termination when not selected: No connection or 0 to 2.5 VDC, 2 mA max.
Start interlock function
(optional)
Default inactive, selectable with F39-U1E
Blanking function
(optional)
Default inactive, selectable with F39-U1E
Indicator See Indicators No Indicators
Connection method For Extension cable: 8 pins M12 connector For Series connection cable: 6 pins M12 connector Connection method For Extension cable: 8 pins, M12 connector. For Series connection cable: 6 pins, M12 connector
Ambient temperature During operation: -10 to 55 °C (with no freezing)
During storage: -25 to 70 °C
Ambient humidity During operation: 35 to 85 %RH (with no condensation)
During storage: 35 to 95 %RH
Insulation resistance 20 MΩ min. (at 500 VDC)
Dielectric strength
voltage
1,000 VAC 50/60 Hz for 1 min
Degree of protection IEC60529 IP65
Vibration resistance Normal operation: 10 to 55 Hz, double--amplitude: 0.7mm, X, Y and Z directions 20 sweeps
Shock resistance Normal operation: 100 m/s 2 [10 G], X, Y and Z directions: 1000 times
Materials Case: Aluminum
Front cover: PMMA (acrylic resin)
End caps: PA6
Size (cross-section) 30 x 40 mm
Accessories Test rod (See Note 3); mounting brackets -- top and bottom, mounting brackets -- intermediate (See Note 4);
mounting plates (See Note 4); instruction manuals (See Note 5).
Applicable standards IEC(EN)61496-1 Type 2 ESPE (Electro-Sensitive Protective Equipment)
IEC 61496-2 Type 2 AOPD (Active Opto-Electronic Protective Devices)
Note: 1 For detailed type names and optical specifications, see Ordering Information.
2 Nominal value (set time). The accuracy is --0. +70% of the ON to OFF response time.
3 Only with F3S--Bjjj2P and BMjjj2Pjj
4 For the 1,050 mm protective height and longer types.
5 Only with F3S--BjjjPj and BMjj2Pjj.
