Omron F3S-B - Manual (Page 10)

F3S-B
11
J
MOUNTING BRACKET (TOP AND BOTTOM)
22
2
R1.75
5.5
R2.75
.
R4.5
∅ 25.5
3.5
20°
35°
46
16 12
30
20
36
J MOUNTING PLATE
Only supplied with types which have a protective height of 1,050 mm or longer (including intermediate brackets). Only needed for rear
mounting.
42.74
36.5
7
5
12
5.5 R2.75
6.25
3
22.5 28.74
4
20
J
INTERMEDIATE MOUNTING BRACKET
12.5
13
12
Mounting screw for
sensor (M6x8)
Flat intermediate
bracket
Rubber
U-shaped
intermediate
bracket
Fixing
screw for
bracket
(M4x10)
L--shaped
intermediate bracket
Note: An Intermediate Mounting
Bracket is only needed for
types which have a protective
height of 1,050 mm or more.
24
5.5
40
16
14 15
11
31.3
3.2
5.5
42
30
15
24
16
24
0.65
3.2
0.65
2
15.5
36
3.5
8
7
