Orion ATLAS EQ-G User Manual
Page 2
2
Figure 1.
The Atlas EQ-G mount.
Power switch
Power indicator light
12V DC power jack
Auto guider jack
Right Ascension
setting circle
Right Ascension
lock lever
Hand controller jack
Latitude scale
Latitude adjustment L-bolts
Center support shaft
Tripod center support tray
GoTo hand controller
Tube ring mounting plate
Mounting plate lock knobs
Declination lock lever
Declination setting circle
Front opening
Counterweight shaft lock lever
Counterweight shaft
Counterweights
Counterweight lock knobs
“Toe-saver”
GoTo hand controller cable
Tripod leg
Leg lock levers
