Manual No. 25-ULPNR102-01; Mar, 2005 LMD 1135 Laser Fixed Mount Scanner

Page 4

Pitch

Specified operation (

α) at + 50 degrees or less. (Recommended at + 13 degrees)

Avoid specular reflection in the dead zone (+/- 8 degrees).

Skew

Specified operation (α) + 30 degrees or less. (Recommended 0 degrees)
