Manual No. 25-ULPNR102-01; Mar, 2005 LMD 1135 Laser Fixed Mount Scanner

Page 2

In the

Properties Settings

dialog screen, Select

Terminal keys

for the Function, arrow and

control key; then Select

ANSI

for Emulation; the

Back scroll

buffer line can remain at the

default 500

Click on the ASCII Setup button. In the ASCII Setup Sending screen, select Line ends with

line feeds and Echo typed locally so that any keyboard commands you input will appear on

your screen. In the ASCII Setup Receiving screen, select Append line feeds to incoming line

ends and Wrap lines that exceed terminal width. Click OK. This returns you to the

Properties Setting. Click OK

4) Your PC and the scanner should now communicate. Skip to Step 6.

5) In a Microsoft Windows 3.1 environment, set the communication parameters using the Terminal

function of Windows.

a) From Window’s

Program Manager

Main Menu, select

Terminal.

From the

Terminal

menu, select Settings.

From the

Settings

menu, select Terminal Emulation.

Set the emulation to TTY (generic).

From the

Settings

menu, select Terminal Preferences and select the following

Terminal Modes:

Line Wrap

Local Echo

Sound

CR /LF: Inbound, Outbound

Columns: 80

From the

Settings

menu, select Communications , select the COM port, and set

communication parameters as shown in Step 2, including no flow control

6) To verify that the scanner and the PC are communicating properly, send the following command

from your PC keyboard which will request software settings to be displayed.

Send the command in four keystrokes: Z3

Note: Be sure to use capital letters, e.g. “Z3”, not “z3”.

A series of software setting should be displayed, indicating that good communications have

been established

7) A red laser light should be visible. If it is not visible, the scanner may be in a mode that requires

a “Trigger” Command from the PC to activate it. You can exit that mode by sending the

following command from your PC keyboard:

S7

8) The “Trigger” mode will now be deactivated and the red laser light will be continuously

illuminated.

This Quick Start-Up procedure will get you started. However, to best understand the full capabilities of

this scanner, you should read the complete manual.
