Manual No. 25-ULPNR102-01; Mar, 2005 LMD 1135 Laser Fixed Mount Scanner

Page 52

22. Code Identification & Characters/Digits Transmitted

This feature instructs the scanner to use pre-existing code identifiers and/or to calculate/transmit a

number indicating the total number of characters that are being transmitted to the host for specific

symbologies. This feature allows the host to verify that the correct amount of data was received. This

information may be transmitted as either a prefix or suffix.

Code identification using the pre-existing symbology codes can be accomplished using the “Code

identification” command as shown in the example below.

Code length is transmitted as 2 or 6 digits depending upon the selection made from the menu below.

These commands can be used together or individually as required.

Computer

Command

Function

/Description

Bar Code

Command

(ZZ)

START/END

Programming Menu

[[

$2

Code identification

%3

$3

Enable code length

2 digits

%!

$6

Enable code length

6 digits

%7

6A

Direct Input Character ”:”

7B

Example:

To set a prefix for “::” scan the following menu items:

< START/END>

Menu below

Section 15 (or specific symbology)

Menu below ($2)

<:>

Menu

below

(6A)

Menu below ($3) or ($6)

<:>

Menu

below

(6A)

Menu

below
