Manual No. 25-ULPNR102-01; Mar, 2005 LMD 1135 Laser Fixed Mount Scanner
Page 7
Scanner/cable snap-in connector pin-out (connector: 3004CA8101 Kinsun)
Pin No. Signal
1 RTS
2 CTS
3 TxD
4 RxD
5 VCC
6 Ground
7 NC
8 NC
9 NC
10 NC
Environmental Specifications
Temperature
Operating +23 to +113 ° F (-5° to +45° C )
Storage -4 to +140 ° F (-20° to +60° C)
Humidity (non- condensing)
Operating 20 to 80% RH
Storage 20 to 90% RH
Ambient Light Fluorescent or incandescent: below 3 kilolux
Ordering Information
Part No. Model
LPN1137RR1S-050 Front View, 9 Pin D-Sub Female Connector (with power stereo jack)
(standard configuration, other configurations are available upon request)
Developer’s Test and Evaluation Kit (LPN-1137R1-SK1) is available which contains all the items needed to
install and evaluate the scanner. The kit includes:
Scanner
5V Power Supply (32-00907-01)
User Manual
CD ROM (including manual, datasheet and supporting materials)
