Manual No. 25-ULPNR102-01; Mar, 2005 LMD 1135 Laser Fixed Mount Scanner
Page 13
Section 4
Configuring the Scanner
Since the operation of the LMD 1135 scanners are microprocessor controlled, it is possible to modify or
program its operation to match your specific application. Changes in parameter settings can be
accomplished two ways.
1. The scanner can be programmed by sending software instructions from the host PC to the scanner
via the RS232 connection.
2. The second method employs specially designed programming bar codes. Scanning these bar codes
instructs the scanner to modify specific parameters.
Programming Menus & Commands
Appendix A contains full instructions on how to configure the scanner as well as a complete listing of the
computer commands and programming bar codes that are available to customize the scanner for your
application.
Default Settings
When you modify or change any parameters, the scanner can be programmed to retain the new
parameter in memory, even if power interrupted or terminated. If for any reason the scanner is
instructed to return all parameters to default settings (U2), it will return to the default settings shown in
the following table.
Default settings are indicated by a pointing hand symbol (
%
) throughout the bar codes menus.
Parameter Factory Default Setting
RS 232 Communications 9600 baud
8 data bits
1 stop bit
No parity
No handshaking
Trigger Function
Auto-Trigger Function Enabled
Enabled
Read Mode Multiple Read Mode
No. of Redundant Decodes Read three times before transmitting
UPC-A (12 digits) No leading zero
Enable check digit
UPC-E (7 digits) No leading zero
Enable check digit
Code 39 Do not calculate check digit/Transmit check digit
Disable start/stop characters (*.....*)
Codabar Disable start/stop characters
Do not calculate check digit
2 of 5 (Interleaved and
Industrial) Do not calculate check digit
Fixed length of bar code only Disabled
Buzzer Enabled
Positive bar codes only Enabled
Error indications Do not transmit error code
