Manual No. 25-ULPNR102-01; Mar, 2005 LMD 1135 Laser Fixed Mount Scanner
Page 22
Handshaking
I0 Unlimited wait for CTS from terminal
I1 100 mS wait for CTS from terminal
I2 200 ms wait for CTS from terminal
I3 400 mS wait for CTS from terminal
P0 No Handshaking
P1 Busy/Ready
P2 Modem
P3 ACK/NAK (1 second timeout with error
buzzer)
P4 ACK/NAK no response (100 ms timeout,
terminates with good read buzzer)
ZG XON/OFF
KA No intercharacter delay
KB 20 ms intercharacter delay
KC 50 ms intercharacter delay
KD 100 ms intercharacter delay
Buzzer Operation
T0 Volume = Maximum
T1 Volume = Upper mid-range
T2 Volume = Lower mid-range
T3 Volume = Minimum
W0 Disable Buzzer
W1 Enable buzzer at 3kHz
W2 Enable buzzer at 3kHz with 2.5kHz interval
W3 Enable buzzer at 3kHz with 4kHz interval
W4 Buzzer duration 0.10 sec
W5 Buzzer duration 0.20 sec
W6 Buzzer duration 0.40 sec
W7 Buzzer duration 0.05 sec
W8 Enable buzzer
Positive & Negative Bar Codes
V2 Positive bar codes only
V3 Only negative bar codes
V4 Both positive and negative bar codes
Setting the Trigger & Auto-Trigger
Functions
S7 Disable the trigger function (Laser On)
S8 Enable the trigger function (Laser OFF until
the trigger is activated )
+F Auto-Trigger Disable
+I Auto-Trigger Enable
Z Activate the trigger; turns the laser ON
Selecting the Read Mode
S0 Single Read Mode (Trigger must be Enabled,
S8)
S1 Multiple Read Mode
S2 Continuous Read Mode
Parallel Read Mode
+6 2 Parallel labels only
+7 3 Parallel labels only
+8 4 Parallel labels only
