20

Specifications

FM
Tuning Range:

European and Worldwide models:

87.50 – 108.00 MHz (50 kHz steps)

USA and Canadian models:

87.90 – 107.90 MHz (200 kHz steps)

Usable Sensitivity:

Mono: 10.3 dBf 0.9

µ

V, 75 Ohms IHF

0.8

µ

V, 75 Ohms DIN

Stereo: 17.2 dBf 2.0

µ

V, 75 Ohms IHF

20

µ

V, 75 Ohms DIN

50 dB Quieting Sensitivity: Mono: 16.1 dBf 1.7

µ

V 75 Ohms

Stereo: 36.1 dBf 17

µ

V 75 Ohms

Capture Ratio:

1.3 dB

Image Rejection Ratio:

100 dB

IF Rejection Ratio:

100 dB

Signal-to-Noise Ratio:

Mono: 85 dB IHF
Stereo: 77 dB IHF

70 dB IHF (Narrow)

Selectivity:

70 dB DIN (

±

300 kHz, 40 kHz dev.)

AM Suppression Ratio:

50 dB

Total Harmonic Distortion: Mono: 0.1%

0.3% (Normal 40 kHz dev.)

Stereo: 0.2%

0.7% (Normal 40 kHz dev.)

Frequency Response:

30 – 15,000 Hz (+0.5, –1.0 dB)

Stereo Separation:

45 dB at 1 kHz
33 dB at 70 – 10,000 Hz

Output Voltage:

1.0 V

Muting Level:

17.2 dBf 2.0

µ

V, 75 Ohms

AM
Tuning Range:

USA and Canadian models:

530 – 1710 kHz (10 kHz steps)

Worldwide models:

531 – 1602 kHz (9 kHz steps)
530 – 1710 kHz (10 kHz steps)

Usable Sensitivity:

25

µ

V

Image Rejection Ratio:

40 dB

IF Rejection Ratio:

40 dB

Signal-to-Noise Ratio:

40 dB

Total Harmonic Distortion: 0.8%
Output Voltage:

250 mV

General
Power Supply:

USA and Canadian models:

AC 120 V, 60 Hz

European models:

AC 230 V, 50 Hz

Worldwide models:

AC 120 V and 220 – 230 V
switchable, 60/50 Hz

Dimensions (W

×

H

×

D): 435

Ч

91

Ч

373 mm

17-1/8

Ч

3-9/16

Ч

14-11/16

Mass:

4.9 kg, 10.8 lbs.

Specifications and features are subject to change without notice.

Troubleshooting Guide

• No power.

Cause

:

Power cord is disconnected.

Remedy: Connect power cord.

• Buzzing noise on AM, usually conspicuous at night or with a weak station.

(For models other than European models)

Cause

:

Noise from electrical apparatus such as fluorescent lamps.

Remedy: Move set to different location.
Remedy: Change the position or direction of the loop antenna.

• High pitch noise.

Cause: Noise from TV.

Remedy: Keep unit away from TV set.

• Crackling noise on AM and FM.

Cause: Noise caused by turning a fluorescent lamp on and off.

Remedy: Move the autenna as far away as possible from the fluores-

cent lamp.

Cause: Noise from automobile ignition.

Remedy: Install an outdoor FM antenna as far away as possible from

the road.

• AM stations cannot be received. (For models other than European models)

Cause: AM loop antenna is not attached.

Remedy: Connect the included AM loop antenna to the AM antenna

terminals.

• TUNED indicators and stereo indicator light but sound is distorted and

separation is bad.

Cause: Station is too strong.

Remedy: Change to T-shaped antenna.

Cause: Multiple reflection of the radio waves because of tall buildings or

mountains.

Remedy: Use antenna which has better directivity and select a point

with the least distortion.

• TUNED indicators and stereo indicator flicker and hiss is heard on FM.

Cause: Station is too weak.

Remedy: Install an outdoor FM antenna.
Remedy: Change the position or direction of the outdoor antenna.

Cause: Stereo FM broadcasts cover only about half the distance of an

ordinary broadcast.

Remedy: Switch to mono reception. (Even stereo broadcasts will be

heard in mono.)

• No station or undesired station is recalled.

Cause: The power cord has been unplugged for a long time.

Remedy: The memory contents are lost if the power is not turned on

and off a few times each month. Store all stations in the
memory again and remember to turn power on and off a few
times each month.

• The RDS function does not work.

Cause: The station is not an RDS station.

Remedy: Receive an RDS station.

Cause: The reception station signal is too weak.

Remedy: Install an outdoor FM antenna.
Remedy: Change the position or direction of the outdoor antenna.

Cause: Too much interference.

Remedy: Move the antenna as far away as possible from fluorescent

lamps.

Remedy: Install an outdoor FM antenna.

• ACCUCLOCK function does not work.

Cause: The station is not an RDS station, or received signal is too weak.

Remedy: See the remedies for the RDS function problem above.

Cause: RDS broadcasts cannot be received.

Remedy: Set and adjust according to instructions above.

• Excessive electrical interference may temporarily render this system’s sensi-

tive microcomputer inoperable. If this happens, unplug the system for at least
five seconds.
