5. EMI And Environmental Type Tests
RuggedCom® RuggedSwitch® 34 RSG2300 Installation Guide Rev 110
Test Description Test Levels
Enclosure Contact +/- 8kV
IEEE C37.90.3 ESD
Enclosure Air +/- 15kV
IEEE C37.90.2 Radiated RFI Enclosure ports 35 V/m
Signal ports +/- 4kV @ 2.5kHz
D.C. Power ports +/- 4kV
A.C. Power ports +/- 4kV
IEEE C37.90.1 Fast Transient
Earth ground ports
a
+/- 4kV
Signal ports 2.5kV common mode @1MHz
D.C. Power ports 2.5kV common, 1kV diff. mode@1MHz IEEE C37.90.1 Oscillatory
A.C. Power ports 2.5kV common, 1kV diff. mode@1MHz
Signal ports 5kV (Fail-Safe Relay output)
D.C. Power ports 5kV IEEE C37.90 H.V. Impulse
A.C. Power ports 5kV
Signal ports 2kVAC
D.C. Power ports 1.5kVDC IEEE C37.90 Dielectric Strength
A.C. Power ports 2kVAC
Table 5.2. IEEE 1613 (C37.90.x) EMI Immunity Type Tests
Test Description Test Levels Severity Levels
IEC 60068-2-1 Cold Temperature Test Ad -40°C, 16 Hours N/A
IEC 60068-2-2 Dry Heat Test Bd +85°C, 16 Hours N/A
IEC 60068-2-30
Humidity (Damp
Heat, Cyclic)
Test Db 95% (non-condensing), 55°C , 6 cycles N/A
IEC 60255-21-1 Vibration 2g @ (10 - 150) Hz Class 2
a
IEC 60255-21-2 Shock 30g @ 11mS Class 2
a
a
Class 2 refers to “Measuring relays and protection equipment for which a very high security margin is required or where
the vibration levels are very high, e.g. for shipboard applications and for severe transportation conditions.”
Table 5.3. Environmental Type Tests
