4. Technical Specifications
RuggedCom® RuggedSwitch® 29 RSG2300 Installation Guide Rev 110
4.5.2. Fast Ethernet (10/100Mbps) Optical Specifications
Order
Code
Mode
Connector
Type
Cable
Type
(µm)
Tx λ (typ.)
(nm)
Tx min.
(dBm)
Tx max.
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.)
(km)
Power
Budget
(dB)
62.5/125 -19 12
FX01 MM ST
50/125
1308
-22.5
-14 -31 -14 2
8.5
62.5/125 -19 12
FX02 MM SC
50/125
1308
-22.5
-14 -31 -14 2
8.5
FX11 MM LC 62.5/125 1310 -19 -14 -32 -14 2 13
62.5/125 -19 12
FX03 MM MTRJ
50/125
1308
-22.5
-14 -31 -14 2
8.5
FX04 SM ST 9/125 1310 -15 -8 -32 -3 20 17
FX05 SM SC 9/125 1300 -15 -8 -31 -7 20 16
FX06 SM LC 9/125 1310 -15 -8 -34 -7 20 19
FX07 SM SC 9/125 1310 -5 0 -34 -3 50 29
FX08 SM LC 9/125 1310 -5 0 -35 3 50 30
FX09 SM SC 9/125 1310 0 5 -37 0 90 37
FX10 SM LC 9/125 1310 0 5 -37 0 90 37
Table 4.7. Fast Ethernet (10/100Mbps) Optical Specifications
4.5.3. Gigabit Ethernet (1Gbps) Optical Specifications
4.5.3.1. Fixed Gigabit Transceivers
Order
Code
Mode
Connector
Type
Cable
Type
(µm)
Tx λ (typ.)
(nm)
Tx min
(dBm)
Tx max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.)
(km)
Power
Budget
(dB)
FG02 SM SC 9/125 1310 -10 -3 -20 -3 10 10
FG03 SM LC 9/125 1310 -9.5 -3 -21 -3 10 11.5
FG04 SM SC 9/125 1310 -5 0 -20 -3 25 15
FG05 SM LC 9/125 1310 -7 -3 -24 -3 25 17
Table 4.8. Fixed Gigabit Transceivers
4.5.3.2. SFP Gigabit Transceivers
Order
Code
Mode
Connector
Type
Cable
Type
(µm)
Tx λ (typ.)
(nm)
Tx min
(dBm)
Tx max
(dBm)
Rx
Sensitivity
(dBm)
Rx
Saturation
(dBm)
Distance
(typ.)
(km)
Power
Budget
(dB)
50/125 0.5
F51 MM LC
62.5/125
850 -9 -2.5 -20 0
0.3
11
FG52 SM LC 9/125 1310 -9.5 -3 -19 -3 10 9.5
FG53 SM LC 9/125 1310 -7 -3 -23 -3 25 16
FG54 SM LC 9/125 1550 0 5 -23 -3 70 23
Table 4.9. SFP Gigabit Transceivers
