4. Technical Specifications
RuggedCom® RuggedSwitch® 26 RSG2300 Installation Guide Rev 110
4. Technical Specifications
4.1. Power Supply Specifications
The power supplies shown in in Table 4.1, “RSG2300 Power Supply Specifications” may be used
for PS1 only, or for both PS1 and PS2 on the RSG2300, or for PS1 only on the RSG2300P. The
RSG2300P uses the PoE power supply specified in
Table 4.2, “RSG2300P Power Supply PoE
Specifications” for PS2.
Input Range
Power Supply Type
Min Max
Internal Fuse Rating
Max. Power
Consumption
a
12 – 24 VDC 10 VDC 36 VDC 6.3A(F)
b
25 W
48 VDC 36 VDC 59 VDC 3.15A(T)
b
25 W
HI (125/250 VDC)
c
88 VAC 300 VDC 2A(T)
bc
25 W
HI (110/230 VAC)
c
85 VAC 264 VAC 2A(T)
bc
25 W
a
Power consumption varies based on configuration. 10/100Base-TX ports consume roughly 1W less than fiber optic ports.
b
(F) Denotes fast-acting fuse (T) denotes time-delay fuse.
c
The “HI” power supply is the same power supply for both AC and DC.
Table 4.1. RSG2300 Power Supply Specifications
Input Range
Power Supply Type
Min Max
Internal Fuse Rating
Max. Power
Consumption
48 VDC 37 VDC 72 VDC 2A(T)
a
68 W
a
(F) Denotes fast-acting fuse (T) denotes time-delay fuse.
Table 4.2. RSG2300P Power Supply PoE Specifications
4.2. Failsafe Relay Specifications
Parameter Value (Resistive Load)
Max Switching Voltage 240VAC, 125VDC
Rated Switching Current 2A @ 240VAC, 0.15A @ 125VDC, 2A @ 30VDC
Max Switching Capacity 150W, 500VA
Table 4.3. Failsafe Relay Specifications
