3. Installation
RuggedCom® RuggedSwitch®
15
RSG2300 Installation Guide Rev 110
Figure 3.5. 1000LX SFP (mini-
GBIC) Module and LC connector
Figure 3.6. 1000LX GBIC connector
3.2.2. Fixed Fiber Transceivers
The following figures show front and top views of the fixed fiber transceiver modules supported
by RuggedSwitch®. Note that when the module daughter card is installed in the unit, most of the
connector body as shown in the illustrations is not visible.
Figure 3.7. 1000LX LC connector
Figure 3.8. 1000LX SC connector
Figure 3.9. ST 10FL connector
Figure 3.10. MTRJ 100FX connector
