1
Quick Start Guide
If you are familiar with ASMi-31, use this quick start guide to prepare the
unit for operation.
Perform the following steps for both the local and the remote units.
1. Disconnect all cables from the units.
2. Open the case of the units.
3. Adjust the jumpers (see Chapter 2, Installation and Setup).
Note Make sure that there is only one clock source in the application. Select one
modem as INT or EXT, and the second modem as RCV.
4. Close the case of the units.
5. Connect the units to the DTEs.
6. Power up the units.
7. Connect the units to the line.
The units should operate properly after a few seconds.
