ASMi-31 Installation and Operation Manual Chapter 5. Card Cage Version
16-03-00 15:51 Power Supply 5-3
5.2 ASMi-31/R Card Version
Figure 5-2 shows the ASMi-31/R card front panel. The LEDs and switches of
the card version are identical in their functionality to those of the standalone
device. For this information, refer to Section 3.1, Controls and Indicators, in
Chapter 3.
The jumper settings are the same as with ASMi-31 standalone version (refer
to Table 2-1).
TD
RD
DCD
LOS
ERR
TEST
RESET
ASMi-31
PWR
RTS
Figure 5-2 ASMi-31/R Front Panel
