Output Adapter
This adapter is used with coaxial RF cable
of to connect your
camcorder to a standard TV (one without
audio/video input jacks) for playback. If
your antenna cable is the flat twin-lead type
attached by two screws, you will also need a
300-75 ohm transformer such as 193983. If
your TV, has 300 ohm VHS screw terminals,
you will need an optional ohm
transformer such as AH01 1.
Coaxial Cables
(104-t)
193983 Cable Transformer
These RF cables are used with the RF output
adapter to connect your camcorder to a standard
TV (one without audio/video input jacks) for
playback.
If your antenna cable is the flat twin-lead type
attached by two screws, you will also need a
300-75 ohm transformer such as 193983.
If your TV has 300 ohm VI-IS screw terminals, you
will need an optional 75-300 ohm transformer such
as
This 300-to-75 ohm transformer is used to connect a
standard 300-ohm antenna twin-lead to a standard round
connector.
AH011 Cable Transformer
This ohm transformer is used to connect a
standard antenna cable, such as or
to the 300-ohm screw terminals on a TV.
AH25 Y-Adapter
This Y-adapter allows you to connect your camcorder’s mono
audio cable to a stereo TV or VCR.
(continued on next page)
