Raymarine Pathfinder Radar Scanners User Manual
Page 63
Appendix A: Specification
5
Note: If the scanner is bought for use with an existing display, contact your dealer/service
agent for the latest display software to ensure you can use all the open array scanner fea-
tures.
48" Antenna
Antenna Type
Slotted waveguide array
Beam Width (nominal)
1.85°
Polarization
Horizontal
Antenna Side lobes
Less than -22 dB
Rotation Rate
24 rpm (nominal)
Receiver
IF Frequency
60 MHz (nominal)
Receiver Characteristic
Semi-log
Receiver Noise Figure
Less than 5 dB
(including Low Noise Converter/Limiter & IF Receiver)
Receiver Bandwidth
12/3/0.7/0.5 MHz
