Rt040 – Raymarine Pathfinder Radar Scanners User Manual
Page 12
Sheet 2 of 2
Certificate No.
RT040
Declaration of Conformity – Schedule of Ancillary
Equipment
The following Raymarine Display Units are combined with the Raymarine 4kW, Open Array Scanner Unit
(transceiver) listed on Sheet 1 to form the operational radar systems. Details of these units are included in the
Technical Construction File:
DISPLAY (one of)
Description Designation
Part
No.
Display Unit, 7" Colour LCD /Chart
C70
E02018
Display Unit, 8" Colour LCD/Chart
C80
E02020
Display Unit, 12" Colour LCD/Chart
C120
E02022
ANTENNA (one of)
Description
Scanner Unit Designation
(Transceiver + Antenna)
Part No.
48" Antenna Array
5S
M92693
72" Antenna Array
7S
M92743
