Chapter 2: Overview
2.1 Introduction
This handbook provides instructions to assist you in the installation and set up of
the following radar scanners:
5S
48" 4 kW Open Array Scanner
7S
72" 4 kW Open Array Scanner
9S
48" 10 kW Open Array Scanner
11S 72" 10 kW Open Array Scanner
These scanner units may be connected to any HSB/hsb
2
or C-Series display unit.
Note:
To achieve full compatibility with a C-Series Display, your Raymarine radar
scanner may require upgrading. Please refer to the C-Series Display
Owner’s
Handbook
, or contact Technical Support for details.
A typical Pathfinder Radar system is illustrated below.
NMEA
SeaTalk
Display Unit
Distribution Panel
D4288-4
Scanner
12/24V Supply
12V Supply
12V Supply
Junction
Box
GPS
Compass
