Raymarine Pathfinder Radar Scanners User Manual
Page 20
cxc
Centre of rotation
Centre of rotation
48"- 1306 mm (51.4 in), 72"- 1928 mm (75.9 in)
100 mm (4 in)
427 mm (16.8 in)
296 mm (11.65 in)
406 mm (16 in)
D4572-4
Weight
Pedestal: 24 kg (53.0 lb)
48" Open Array: 6 kg (13.2 lb)
72" Open Array: 9.4 kg (20.7 lb)
140 mm (5.5 in)
Minimum clearance height 510 mm (20.1 in)
150 mm (6 in)
Minimum clearance 630 mm (24.8 in)
70 mm
(2.75 in)
Compass Safe Distance: 1 m (33 in)
