Raymarine Pathfinder Radar Scanners - Manual (Page 30)

cc
Table 2-5: Max. Extension Power Cable Lengths (m), 24 V Systems -
10 kW Scanners
Inter-Unit Cable(s) Power Cable Core (each core)
mm
2
:
AWG:
1.5
16 2.0
15 2.5
14 4.0
11
5 m Heavy 12.0 16.0 20.0 32.0
10 m Heavy 10.5 14.0 18.0 28.0
15 m Heavy 9.0 12.0 16.0 24.0
15 m Heavy + 5 m ext 7.5 10.0 13.0 20.0
15 m Heavy + 10 m ext 6.0 8.0 10.0 16.0
25 m Heavy 6.0 8.0 10.0 16.0
25 m Heavy + 5 m ext 4.5 6.0 8.0 12.0
25 m Heavy + 10 m ext. 3.0 4.0 5.0 8.0
Table 2-6: Max. Extension Power Cable Lengths (m), 32 V Systems -
10 kW Scanners
Power Cable Core Size (each core)
mm
2
:
AWG:
1.5
16 2.0
15 2.5
14
10 kW Scanners
≤15.0 ≤20.0 ≤25.0
