Cable details
The following diagrams - one for the inter-unit cable, one for the split pedestal and
adaptor cable - illustrate the connector pins and cable core details.
1 2
3 5
4
7
10
11
8 6
9
13 12
Black
White
Orange
Black
Black
Green
Yellow
Shield
Red
Red
Violet
Blue
Grey
Video
Video RTN
* Battery --ve
Tx Trigger +
Battery --ve
Data I/O +
Tx Trigger --
Battery +ve
Data I/O --
* Battery +ve
Azimuth +
Azimuth --
1
2
3
4
5
6
7
8
9
10
11
12
13
8
7
6
5
4
3
2
1
8
7
6
5
4
3
2
1
White
Black
Orange
Yellow
Green
Blue
Purple
Grey
Red
Red
Black
Black
Video
Video Rtn
Tx Trigger +
Tx Trigger --
Data I/O +
Data I/O --
Azimuth +
Azimuth --
Battery +ve
* Battery +ve
* Battery --ve
Battery --ve
Radome
Connector Open Array Connector
(Pathfinder display only) Display Connector
Inter-Unit Scanner Cable
Display connections Scanner connections
* Not present on 'light', 11 core cables.
Battery +ve/--ve = 12 or 24v.
D4290-4
2
1
4
3
6
5
8
7
