Appendix C IR-IP Interface Module ASM-60 Installation and Operation Manual
C-14 Advanced Setup Menu
➤ To access the Advanced Setup menu:
• From the Main menu, press 3.
The Advanced Setup menu appears (Figure C-9).
IR_IP S/W Ver. 1.00 31/IR (date)
Quick Setup
Management Access
Advanced Setup
=====================================================================
1. Device identification
2. Interface Parameters
3. Protocol Parameters
4. Multicast IP
Press one of the numbers to select or ESC:
Figure C-9. Advanced Setup Menu
Device Identification Menu
The Device Identification menu is used to define and store in the IR-IP logistic
information: the logical name of IR-IP, information on the contact person and
device location.
➤ To access the Device Identification menu:
• From the Advanced Setup menu, type 1.
The Device Identification menu appears (Figure C-10).
IR_IP S/W Ver. 1.00 31/IR (date)
Quick Setup
Management Access
Advanced Setup
.....................................................................
Device identification
=====================================================================
1. Device Name :IR-IP..
2. Contact Person :Name of contact Person
3. System Location :The location of this device
Press one of the numbers to select or ESC:
Figure C-10. Device Identification Menu
Device Name
Select this parameter to assign an arbitrary name to IR-IP for identification by the
system manager (up to eight characters). The assigned name is displayed in the
screen header.
