Appendix C IR-IP Interface Module ASM-60 Installation and Operation Manual
C-10 Quick Setup Menu
To end the utility, press when the Main menu is displayed. This will also
end the Telnet session.
Menu Structure of Management Utility
Figure C-5 shows the menu structure of the IR-IP management utility.
Main Menu
1. Quick Setup
1. LAN IP Address
2. LAN IP Mask
3. WAN IP Address
4. WAN IP Mask
5. Default Gateway
6. Read Protocol From DIP Switches
7. Protocol
1.Telenet Password
2. Telenet Activity Timeout
3. SNMP Access
4. SNMP Read Community
5. SNMP Write Community
6. SNMP Trap Community
7. SNMP Management Table
1. Device Identification
1. Device Name
2. Contact Person
3. System Location
1. New Software Download
1. Server IP Address
2. File Name
3. Total Timeout
4. Start Operation
1. Configuration and Connection
2. ARP Tables
3. Multicast Groups Table
4. Statistics
1. Ping IP Address
2. Start Pinging
3. Stop Pinging
2. View Error Log
3. Resets
1. Reset Device
2. Reset LAN
3. Reset WAN
2. Interface Parameters
1. LAN Status
2. WAN Status
3. WAN Throttle
4. Aging Timeout
3. Protocol Parameters (FR)
1. Self Learn
2. Maintenance Protocol
3. DLCI
4. CIR
5. EIR
3. Protocol Parameters (PPP)
1. Header and Control Field Compression
2. Protocol Field Compression
3. Authentication Protocol
4. Security Host/Guest
5. User Name To Send
6. Password To Send
7. User Name To Accept
8. Password To Accept
4. Multicast
1. Multicast Forwarding
2. Static Groups
2. Management
Access
3. Advanced Setup 4. Device Control 5. View
6. Diagnostic Tool
PING Terminal
Figure C-5. Management Utility, Menu Structure
C.7 Quick Setup Menu
The Quick Setup menu is used to select the main parameters’ values that must be
defined before you start using IR-IP.
Use the Advanced Setup menu (see the Advanced Setup Menu section below) to
specify values for other IR-IP configuration parameters not included in this menu.
➤ To access the Quick Setup menu:
• From the Main menu, type 1.
The Quick Setup menu appears (Figure C-6).
