Appendix B IR-ETH/QH Interface Module ASM-60 Installation and Operation Manual
B-4 Installation and Operation
LED Indicators
Table B-3 lists the IR-ETH/QH rear-panel LED indicators and describes their
functions.
Table B-3. IR-ETH/QH LED Indicators
LED Name Color Description Location
LINK Green ON – LAN is connected to the IR-ETH/QH
module Connector
ACT Yellow ON – LAN is receiving/transmitting data Connector
100 Green ON – LAN is operating at 100 Mbps
OFF – LAN is operating at 10 Mbps Panel
Connecting the LAN
Use either a straight cable or a cross cable for the LAN connection.
Use a cross cable when connecting to a port that does not implement the
crossover function internally. Otherwise, use a straight cable.
Hubs usually implement the crossover function internally, while NICs and other
devices do not.
Note
