IMPORTANT
Notes on Product Information:
• For the information about this product, visit the Renesas Tool Homepage.
http://www.renesas.com/eng/products/mpumcu/toolhp/mcu/m32r_e.htm
• For the user registration for this product, use the registration form created when installing the
emulator debugger. To registered users, the latest information about this product is delivered by
e-mail.
• This product contains the CD-ROM of the emulator debugger, but it is also possible to download
the latest version of the emulator debugger from the Renesas Tool Homepage.
http://www.renesas.com/eng/products/mpumcu/toolhp/mcu/m32r_e.htm
Notes on Downloading Firmware:
• When using this product for the first time or the emulator debugger has been upgraded, the emulator
debugger automatically downloads the firmware (control software for the emulator built into it) to
the emulator. When downloading firmware is terminated normally, the firmware will not be
downloaded later.
• Do not shut down the emulator while downloading the firmware. If this happens, the product will
not start up properly.
• When downloading the firmware has not completed successfully and the emulator debugger does
not start up, see "4.2 Downloading Firmware" (page 29) and redownload the firmware.
Notes on USB Interface:
• USB interface can not be used with a host machine running Windows 95 or Windows NT 4.0.
• With the USB interface of the M32100T-EZ-E, not all hardware (such as host machine, USB
devices, USB hub) combination will work and guaranteed.
Notes on Dependencies on the MCU Model:
• As the following items dependent on the MCU model are described in the release notes, be sure to
read them.
(1) Differences between the emulator and actual MCU
(2) MCU signals connected to the SDI MCU control interface connector (Section 3.2)
(3) Debug specifications dependent on MCU model (Section 5.1)
(4) Other cautions and restrictions dependent on MCU model
• Download the latest release notes and MCU file from the Renesas Tool Homepage.
http://www.renesas.com/eng/products/mpumcu/toolhp/mcu/m32r_e.htm
Note on Stack Capacity and Stack Pointer:
• Set an address which has the device to read/write to the SPI (Stack Pointer for Interrupt) and SPU
(Stack Pointer for User) during target program execution.
