M301N2T-PRB User’s Manual

2. Setup

REJ10J0037-0100 Rev.1.00 Mar.16, 2005

Page 23 of 48


2.5 Connecting the User System

Connect the emulation pod to the user system as shown in Figure 2.7.

Figure 2.7 Connecting the user system

















M30102T-PTC

Pod probe
M301N2T-PRB

48-pin 0.5-mm-pitch

LQFP

Emulation pod
M30100T3-RPD-E

: No.1 pin

User system
