Rev.7.00, Jan.29.2004, page 1 of 8
HD74HCT1G66
Analog Switch
REJ03D0197–0700Z
(Previous ADE-205-308E (Z))
Rev.7.00
Jan.29.2004
Description
The HD74HCT1G66 is high-speed CMOS analog switch using silicon gate CMOS process. With CMOS
low power dissipation, it provides high speed. The device has low ON resistance for good transfer
characteristics and can take wide range of input voltage.
Features
• The basic gate function is lined up as Renesas uni logic series.
• Supplied on emboss taping for high-speed automatic mounting.
• Control input is TTL compatible input level.
Supply voltage range : 4.5 to 5.5 V
Operating temperature range : –40 to +85°C
• |I
OH
| = I
OL
= 2 mA (min)
• Ordering Information
Part Name Package Type Package Code Package
Abbreviation Taping Abbreviation
(Quantity)
HD74HCT1G66CME CMPAK-5 pin CMPAK-5V CM E (3,000 pcs/reel)
