M301N2T-PRB User’s Manual 2. Setup
REJ10J0037-0100 Rev.1.00 Mar.16, 2005 Page 20 of 48
2.2 Switch Settings
It is necessary to set the switches of the FLX64-PRB for debugging according to the user system. Figure 2.3 shows the
positions of the switches of the FLX64-PRB, and Table 2.2 shows the switch settings.
Figure 2.3 Positions of the switches and their factory-settings
Table 2.2 Switch settings of the FLX64-PRB
Signal Switch Switch Setting of jumper switches
PORT PORT
XCIN XCIN
JP1 P47/X
CIN
When using the P47/X
CIN
as a
port (Factory-setting)
When using the P47/X
CIN
as XCIN
PORT PORT
NC NC
FLX64-PRB
JP2 P46/X
COUT
When using the P46/X
COUT
as a
port (Factory-setting)
When not connecting the
P46/X
COUT
CAUTION
Note on Switch Settings:
Always shut OFF power before changing switch setting. Otherwise, internal circuit board may be
damaged.
PO
R
T
PO
R
T
JP1
JP2
XC
IN
NC
FLX64-PRB board
