HD74CBT1G125

Single FET Bus Switch

REJ03D0815-0100

(Previous: ADE-205-645)

Rev.1.00

Apr 07, 2006

Description

The HD74CBT1G125 features a single high-speed line switch. The switch is disabled when the output enable (

OE)

input is high.

Features

Minimal propagation delay through the switch.

5

switch connection between two ports.

TTL-compatible input levels.

Ultra low quiescent power.

Ideally suited for notebook applications.

Ordering Information

Part Name

Package Type

Package Code

(Previous code)

Package

Abbreviation

Taping Abbreviation

(Quantity)

HD74CBT1G125CME CMPAK–5pin

PTSP0005ZC-A
(CMPAK–5V)

CM

E (3,000pcs / Reel)

Outline and Article Indication

• HD74CBT1G125

Marking

= Control code
( or blank)

B B

Index band

CMPAK–5

Function Table

Input

OE Function

L

A port = B port

H Disconnect

H: High

level

L: Low

level
