Rimage EverestTM Printer - Manual (Page 29)

Maintain the Everest printer
110632_L 23
2. Discard the used retransfer ribbon.
3. Install the new retransfer ribbon.
a. Remove the retransfer ribbon from
the packaging.
b. With the supply roll on the left side,
slide both retransfer rolls under the
retransfer ribbon carrier.
c. Install the supply roll on the left side
of the carrier and snap the roll into
place.
d. Bring the take up roll up and around
the guide rollers and snap the roll into
place.
Supply roll
Take up roll
e. Ensure that the retransfer ribbon is
aligned and straight across all the
ribbon guides.
f. To take up the ribbon slack, turn the
take up roll counterclockwise
4. Reassemble the printer.
Position of
lower guide
a. Slide the retransfer carrier into the printer.
b. Close latches 1, 2, and 3.
c. Close the side cover.
5. Power on the printer. The printer is ready.
