Rimage EverestTM Printer - Manual (Page 28)

Rimage Everest Printer
22 110632_L
Changing the retransfer ribbon
Before changing the Everest retransfer ribbon, allow time for the new ribbon to become
acclimated to the environment. Allow more time for greater temperature and/or humidity
differences.
Ribbons must be stored at a temperature between 50°– 90°F (10–32°C). Avoid moisture and
direct sunlight. Do not reuse ribbons.
Before you begin:
Power off the printer.
1. Remove the retransfer ribbon.
a. Press the two cover latches to
release the side cover.
b. Lower the side cover.
Cover latches
c. Open latches 1, 2, and 3.
d. Pull out the retransfer ribbon carrier.
Note: The retransfer ribbon
carrier cannot be removed from
the printer. Side cover
Retransfer ribbon carrier
e. To remove the retransfer ribbon from
the carrier, lift the retransfer rolls up
and carefully slide the retransfer
ribbon from the retransfer ribbon
carrier.
Latch 2
Latch 3
